Description
OmnyX
Your Build. Your Vision. Any Side You Like.
The OmnyX gives you the power to play, create and perform with unprecedented flexibility. Experience true freedom of orientation and maximum airflow with COUGAR’s revolutionary Omnidirectional Dynamic Flow System. Take a side, and showcase your masterpiece.
Specifications
| Product Name | OmnyX | |
|---|---|---|
| Case Form Factor | Mid Tower | |
| Motherboard Type | Mini ITX / Micro ATX / ATX | |
| Dimensions (WxHxD) | 300(W) x 520(H) x 470(D) (mm) 11.8(W) x 20.5(H) x 18.5(D) (in) |
|
| I/O Panel | USB 3.2 Gen 2 Type-C x 2, USB 3.0 Type-A x 4, 4 Pole Headset Audio Jack x 1 | |
| 3.5″ Drive Bay | 2 | |
| 2.5″ Drive Bay | 2 | |
| Expansion Slots | 7 (horizontal slots can be converted into vertical slots) | |
| Cooling Fan Support | Front | *120mm x 2 / *140mm x 2 / 160mm x 2 |
| M/B Side | 120mm x 3 | |
| Rear | *120mm x 2 / *140mm x 2 / 160mm x 2 | |
| Pre-installed Fans | Front | 160mm ARGB PWM fan x 2 (Forward Blade) |
| Rear | 160mm ARGB PWM fan x 2 (Reverse Blade) | |
| Speed | 300-1200 ? 10% RPM | |
| Connector | 5V 3 Pin (ARGB) / 4 Pin PWM (Fan) | |
| Maximun Number of Fans | 7 | |
| Water Cooling Support | Front | *280mm / *240 mm / *140 mm / *120mm |
| M/B Side | 360mm / 240mm | |
| Rear | *280mm / *240 mm / *140 mm / *120mm | |
| RGB Hub Sync with M/B | Yes | |
| Max. Graphics Card Length | 380(mm) / 15(in) | |
| Max. CPU Cooler Height | 170(mm) / 6.7(in) | |
| Max. PSU Length | 200(mm) / 7.9(in) | |
